Product Type:
Contactor
Coil Voltage:
230 V
Number of Poles:
4
Contact Voltage:
690V
Contact Current:
10A
Power Rating:
150VA
Series:
CA2KN
Mount Type:
DIN Rail
Function:
Control Relay
Normal State Configuration:
4 NO
Number of Auxiliary Contacts:
4
Auxiliary Contact Configuration:
4 NO
Terminal Type:
Screw Clamp
Minimum Operating Temperature:
-25°C
Contactor Application:
Control Circuit
Control Circuit Voltage Uc:
230 V
Maximum Operating Temperature:
50°C
Length:
58mm
Depth:
57mm
Standards/Approvals:
RoHS, CB scheme, CCC, CE, CSA, CSA C22.2 No 60947-4-1, EAC, EN/IEC 60947-4-1, GB/T 14048.4, JIS C8201-4-1, REACH, UKCA, UL, UL 60947-4-1
Width:
45 mm
Better World Product:
Yes
Distrelec Product Id:
30112049
Pole and Throw Configuration:
4
