Coil Voltage:
24 V ac
Product Type:
Contactor Relay
Number of Poles:
4
Contact Voltage:
415V
Contact Current:
4A
Series:
DILA
Mount Type:
DIN Rail
Normal State Configuration:
2 NO/2 NC
Auxiliary Contact Configuration:
2 NO/2 NC
Number of Auxiliary Contacts:
4
Terminal Type:
Screw
Minimum Operating Temperature:
-25°C
Control Circuit Voltage Uc:
24 V
Maximum Operating Temperature:
60°C
Depth:
125.2mm
Length:
45mm
Standards/Approvals:
CSA Class No.: 3211-03, CE, CSA, CSA-C22.2 No. 14-05, CSA File No.: 012528, CSA Std. C22.2 No. 14-05, EN 60947-4-1, EN 60947-5-1, IEC 60947-4-1, IEC/EN 60947, IEC/EN 60947-4-1, UL, UL 508, UL Category Control No.: NKCR, VDE 0660, VDE UL File No.: E29184
Width:
68 mm
Pole and Throw Configuration:
4
