Broadcom 5V dc Optical Encoder with a 1/4 in Hollow Shaft

Manufacturer:

Manufacturer Part No:

HEDS-5500#A06

Enrgtech Part No:

ET14054280

Warranty:

Manufacturer

JOD 52.61

Checking for live stock

Pulses Per Revolution:

500

Encoder Reading:

Incremental

Encoder Signal:

2 Channel Quadrature

Counts per Revolution:

500

Supply Voltage:

5V dc

Shaft Diameter:

1/4 in

Shaft Style:

7.2 x 3.5 x 7.5mm

Maximum Operating Speed:

30000rpm

0900766b80026837.pdf(datasheets)

0900766b8140a577.pdf(datasheets)
