Manufacturer Series:
EasyE4
Number of Inputs:
4
Output Type:
Transistor
Supply Voltage:
24 V dc
Input Type:
Digital
Number of Digital Inputs:
4
Number of Outputs:
4
Voltage Category:
24 V
Network Type:
Ethernet
Number of Digital Outputs:
4
Dimensions:
36 x 58 x 90 mm
Standards Met:
CSA C22.2 No.61010, cULus acc. to UL 61010, EN 50178, EN 61000-6-2, EN 61000-6-3, EN 61010, IEC 60068-2-27, IEC 60068-2-30, IEC 60068-2-6, IEC 61131-2
Display Included:
No
Depth:
90mm
Minimum Operating Temperature:
-25°C
Length:
36mm
Mounting Type:
Wall Mount
Programming Language Used:
Easy Programming EDP, Function Block Diagram (FBD), Ladder Diagram (LD), Structured Text (ST)
Number of Analogue Outputs:
0
Width:
58mm
Maximum Operating Temperature:
+55°C
Number of Analogue Inputs:
0
