Relpol PCB Mount Power Relay, 24V ac Coil, 8A Switching Current, DPDT

Relpol PCB Mount Power Relay, 24V ac Coil, 8A Switching Current, DPDT

Manufacturer:
Manufacturer Part No:
RM84-2012-35-5024
Enrgtech Part No:
ET16806813
Warranty:
Manufacturer
JOD 6.53
Checking for live stock
Coil Voltage:
24V ac
Contact Configuration:
DPDT
Mounting Type:
PCB Mount
Switching Current:
8A
Number of Poles:
2
Latching:
No
Series:
RM84
Terminal Type:
Plug In
Maximum Switching Voltage AC:
440V
Maximum Switching Voltage DC:
24V dc
Length:
29mm
Coil Resistance:
400Ω
Coil Power:
750mW
Standards Met:
CSA, cULus, EAC, PN-EN 60335-1, VDE
Maximum Operating Temperature:
+70°C
Minimum Operating Temperature:
-40°C
Life:
>100000 (Electrical) cycles, >30000000 (Mechanical) cycles
Depth:
12.7mm
Height:
15.7mm
Isolation Coil To Contact:
5kV ac
Contact Material:
Silver Alloy
Maximum Switching Power AC:
2 kVA
pdf icon
0900766b81510737.pdf(datasheets)
